The Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP works on innovative solutions in the fields of vacuum coating, surface treatment as well as organic semiconductors. The core competences electron beam technology, sputtering and plasma-activated deposition, high-rate PECVD as well as technologies for the organic electronics and IC/system design provide a basis for these activities. Thus, Fraunhofer FEP offers a wide range of possibilities for research, development and pilot production, especially for the processing, sterilization, structuring and refining of surfaces as well as OLED microdisplays, organic and inorganic sensors, optical filters and flexible OLED lighting. Our aim is to seize the innovation potential of the electron beam, plasma technology and organic electronics for new production processes and devices and to make it available for our customers. Our technologies and processes can be used for innovations in mechanical engineering, in transport, in biomedical engineering, in architecture and preservation, in packaging, in the field of energy and environment, on optics, sensors and electronics as well as in agriculture.

Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP

Winterbergstraße 28

01277 Dresden

Germany

Phone +49 351 2586-0

Fax +49 351 2586-105

Latest News

28.9.2018

Scientists of the Fraunhofer FEP participate in the CeTI Cluster of Excellence

After the announcement of the positive decision for the cluster of Exellence CeTI (Center for Tactile Internet with Human-in-the-Loop) of the Technische Universität Dresden (TUD), the scientists of the Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP in Dresden are also pleased about new opportunities for research and development of solutions for efficient cooperation between human and human as well as humans and machine. With more than 10 years of experience in manufacturing of OLED microdisplays, the research institute will contribute to the development of mobile displays with multimodal feedback.
Read more

25.9.2018

Hygiene at your fingertips with the new CleanHand Network

The Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP has been involved in developing processes and equipment for cleaning, sterilization, and surface modification for decades. The CleanHand Network for development of systems and technologies to clean surfaces, materials, and objects was established in May 2018 to bundle the expertise of many partnering organizations. As a partner in the CleanHand Network, Fraunhofer FEP will present the Network and current research topics of the Institute in the field of hygiene and cleaning at the parts2clean trade fair, October 23-25, 2018 in Stuttgart, at the booth of the Fraunhofer Cleaning Technology Alliance (Hall 5, Booth C31).
Read more

19.9.2018

Enjoying virtual-reality-entertainment without headache or motion sickness

The Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP is a provider of research and development services for OLED-on-silicon-technology. At the awe europe 2018, in Munich/Germany, the institute will present large-area high-resolution low-power OLED microdisplays suitable for the next generation of compact VR glasses. A Prototype of VR glasses and the new displays can be seen from October 18th to 19th, 2018 at booth no. 322.
Read more

14.9.2018

Effective deposition of thin insulating layers for sensors in hydrogen technology

Scientists at the Fraunhofer Institute for Organic Electronics, Electron Beam and Plasma Technology FEP have investigated new approaches for depositing low-defect insulating layers, part of the joint project “NaFuSS“ (German Federal Ministry of Education and Research/BMBF promotional reference number 13N13171). The aim is to increase the reliability and durability of pressure sensors for hydrogen technology, an area that is becoming increasingly important. The new approaches and results of the study will be presented at both the 16th International Conference on Plasma Surface Engineering PSE in Garmisch-Partenkirchen, Germany, September 17-21, 2018 and at electronica 2018 (Booth 426 in Hall C5) in Munich, Germany, November 13-16, 2018.
